Waking up devices in (Home Assistant)

This is a quick post on a challenge I had to overcome while integrating my SmartTV (an LG TV 55UJ620V) with

I wanted to be able to turn on the TV (as such allowing automations to be built on top of it, or for example turning it on through a voice command via Google Assistant). As such I first resorted to using the Home Assistant Wake on LAN built in integration ( It kind of worked, but was not very reliable (perhaps 2 out of 5 times it would work).

I knew that by definition, the way that (Wake-up On LAN) WOL is implemented is inherently unreliable: essentially the target (dormant) device is expecting a frame with a specific pattern of bytes. If it receives that frame, it wakes up the host, otherwise nothing happens. The device will normally scan for that pattern of bytes in the frame regardless of the type of transport level protocol it may be on top of. In the case of WiFi in particular, there is the probability (high or low, depending on the network conditions) of that single frame not reaching the destination. This probability increases with the more hops we have in between.

With this implementation I was requiring the magic packet to be sent from a host (the Raspberry Pi where I keep running) that is in a separate router vlan, from where the TV is (these are connected via Ethernet and WiFi respectively):

In order to target reliability I scrapped this approach altogether. As both my router and repeater are OpenWRT based, I started by installing the etherwake package onto the repeater, given that this is the closest note to the TV set:

Tested the tool manually and confirmed that it worked:

It was now a matter of scripting it, and for improved reliability, make sure that the script tests the connection after it tries to turn on the TV.

As a quick dirty approach and knowing that the OpenWRT repeater runs a web server, I went for writing a simple cgi-bin shell script that could be called from another host (making a very basic REST web service). This script would just have to send the WOL packet, and for a while check if the TV comes online. If it doesn't it sends the WOL packet a few more times, and tests the TV again:

root@griffinnet-zh-repeater:/www/cgi-bin# cat


echo "Content-type: application/json"
echo ""

if [ -z "$QUERY_STRING" ]; then
    echo "{\"status\":\"error\"; \"message\":\"MAC and IP addresses not specified.\"}"
    exit 1
    MAC_ADDR=$(echo "$QUERY_STRING" | sed -n 's/^.*mac=\([^&]*\).*$/\1/p' | sed "s/%20/ /g")
    IP_ADDR=$(echo "$QUERY_STRING" | sed -n 's/^.*ip=\([^&]*\).*$/\1/p' | sed "s/%20/ /g")


while [ $i -lt "$MAX_RETRIES" ]; do
    WOL_RESULT=$(etherwake -D -i br-lan $MAC_ADDR)

    if [ ! $? -eq 0 ]; then
        echo "{\"status\":\"error\"; \"message\":\"Wake-up On LAN command failed.\"}"
        exit 1

    ping -c $NUM_PINGS $IP_ADDR > /dev/null


    if [ $PING_RESULT -eq 0 ]; then
        echo "{ \"status\" : \"success\"; \"message\" : \"WOL: $WOL_RESULT; Ping Result: $PING_RESULT\" }"
        exit 0

echo "{\"status\":\"error\"; \"message\":\"Exhausted retries. Unable to wake up device.\"}"
exit 1

On the side, it was a matter of registering for this REST endpoint, and use it as the service that turns on the TV, instead of the built-in Wake on LAN integration:

    url: '{{tv_mac}}&ip={{tv_ip}}'
    method: GET
      accept: 'application/json, text/html'
    content_type: 'application/json; charset=utf-8'
    timeout: 60

  - platform: webostv
    name: TV Sala
    filename: webostv.conf
    timeout: 5
      - service: rest_command.wake_up_device
          tv_mac: 'B4:E6:2A:??:??:??'
          tv_ip: ''
        - livetv
        - youtube
        - netflix

Given that the this REST endpoint takes some time to respond (due to the number of pings it performs to test the connection to the TV), the response timeout was increased to 60 seconds.

This is all that it was needed, and so far the feature have been working flawlessly.

Monday, October 28, 2019

Building a kick-ass home automation by reflashing the Sonoff devices with Tasmota and getting it all working with

For some time I have been gradually bringing more devices to my house, which are either designed or having features allowing these to be integrated to a home automation system.

In spite of all the concerns that can arise from bringing smart/connected devices to the place where you expect personal privacy to exist, the convenience of having these ends up speaking louder overall..

It all started with having a set of unrelated devices in the house, each featuring connectivity and some cloud-based features provided by the vendor. This is the case for the Xiaomi Rockrobo vacuum cleaner, the Sonoff switches, the multimedia devices such as the TV set (an LG smartTV), and also the Google Chromecast and Assistant devices.

I wanted to integrate these, and acquire the potential for doing some home automation, even if to a modest extent. As such, and given the fact that I already had some hardware, notably a Raspberry Pi lying around, I decided to give the Home Assistant project a try, in its easier to setup form, the package (

All it took was an available Raspberry Pi 2 device, and a MicroSD card with sufficient space (a 64 GB one did fine).

Then it was a matter of installing according to the documented procedure, and configuring the integrations. Mostly a walk in a park for someone used to integrating systems, and also the most popular integrations are well documented. For most of the issues that can appear, there is good help in forums as well, as these are previously carved paths for some people.

When I reached the point of integrating the couple of Sonoff switches (one Sonoff TH10 and a Sonoff Dual R2),

I first started with the stock firmware and went for an integration that would sit on top of it. I tried this project:

It is a great solution for starters, and it provides some level of funcionality in Home Assistant, most notably being able to turn the relays on and off.

But in particular for the heater in my living room (in which case I replaced the original faulty control board by the Sonoff TH10), I wanted the thermostat feature to be controllable via the, which wasn't possible using this "over-the-top" integration (unless I defined a "soft thermostat" in itself but I didn't wanted to go with that approach due to the network dependency - if it breaks you are not sure if the heater will stay on or off - better be safe than sorry).

That's where I found that the only option was to reflash the Sonoff's, and completely remove the dependency on the chinese cloud (the original app and the sonoff devices communicate with a cloud-based backend), and no longer require these indirect integrations.

The Tasmota project ( was the obvious way to go. Aimed at running in most Sonoff ESP8266 based devices, this solution has a number of powerful features, making it a good option for those who want to have full control of their IoT devices, and control the integration from both ends ( and the device).

Flashing the devices was not complicated. First had to open the case, and add the 4-pin header for the serial port. These ESP microcontrollers have the characteristic of not requiring special programming hardware - a regular RS-232 serial at 3.3 Volt logic levels is all that is required:

For flashing the image, I used this tool:

There is a self-contained Windows binary, that makes it easy to proceed with the flashing.

As the USB - Serial converter I used a FTDI FT232RL based board. You can get these anywhere, and these have the advantage of providing both 3.3 and 5 volts of both power and logic levels for the RS-232 communication:

For both Sonoff modules (the TH10 and the Dual R2), I have chosen the "Dual Output - DOUT" mode, and made sure to select "yes - wipes all data" (in the TH10 I forgot to do that, and the device wouldn't boot).

The rest was a matter or proceeding with the well documented initial configuration steps:

Once it was up, it was nice to see that the firmware boots up quite quicly, and a simple yet functional Web UI can be accessed:

The relevant challenge for me (and probably the best take away of this blog post) was the setup of the thermostat:

Tasmota doesn't have a ready to use thermostat feature. Rather, it has a relatively powerful rules engine which can be used to define some authomations in the device itself.

Each rule is a set of  "ON trigger DO command [ENDON | BREAK]" clauses, and several rules can be configured, as long as there is free flash memory to do so.

I started from an example in the rules cookbook (, and made the needed adaptations in order to have the thermostat working in my setup.

I made a first iteration based on the example in the cookbook, but as I was integrating with, I realized that the later is currently unable (in its climate MQTT component) to map the predefined climate control status such as 'off' and 'heat' to the '0' and '1' values that the rule was initially expecting.

As such I ended up having to modify the rule accordingly. In my particular setup, I am using anAM2301 sensor (it has both a temperature and an humidity sensor built in):

so the rule had to also be adjusted to point to the correct sensor type.

The rule turns out to be the following:

on system#boot do RuleTimer1 70 endon
on Switch1#State do event toggling1=%mem1% endon
on event#toggling1=off do mem1 heat endon
on event#toggling1=heat do mem1 off endon
on Rules#Timer=1 do backlog var1 0; RuleTimer1 70; power1 0 endon
on tele-AM2301#Temperature do backlog var1 0; RuleTimer1 70; event ctrl_ready=heat; event temp_demand=%value% endon
on event#ctrl_ready=%mem1% do var1 1 endon
on event#temp_demand<%mem2% do power1 %var1% endon on event#temp_demand>%mem3% do power1 0 endon

After the rule is set (the rule can be added to Tasmota through the Web UI console or via the MQTT appropriate topic. E.g. "cmnd/sonoff/Rule1"), the one off initialization procedure must be sent:

backlog SwitchMode1 3; Rule 1; Rule 4; TelePeriod 60; SetOption26 1; SetOption0 0; poweronstate 0; mem1 off; mem2 10; mem3 10; var1 0

This resets the configurations and variables to the correct initial state.

For this device, I have also chose to have the blue status LED be always on, allowing me to know if the heater is energized:

LedPower 1

Basically this rule starts by initializing a timer RuleTimer1 when the device boots up. This timer expires every 70 seconds. Every time this timer expires, the following rule entry is evaluated:

on Rules#Timer=1 do backlog var1 0; RuleTimer1 70; power1 0 endon

It causes the timer to reset, and  variables and power status to be reset. It acts like a watchdog if nothing else is triggered, causing the heater to be turned off.

The second rule entry causes the physical switch in the Sonoff to create an event that will be used to toggle the thermostat through the next two entries:

on event#toggling1=off do mem1 heat endon
on event#toggling1=heat do mem1 off endon

Everytime the temperature sensor is read (every 60 seconds, as set by the TelePeriod 60 command), the corresponding rule entry is evaluated:

on tele-AM2301#Temperature do backlog var1 0; RuleTimer1 70; event ctrl_ready=heat; event temp_demand=%value% endon

This causes the temp_demand variable to be set according to the current temperature (it will later be used to decide if the heater should be turned on or off). The watchdog is reset and the control variables set.

The next rule entry:

on event#ctrl_ready=%mem1% do var1 1 endon

Is used to decide if the thermostat should stay in operation, if mem1 (which is used from MQTT to enable or disable the thermostat) matches the indended operational state (which is "heat" if a temperature event was received).

The last two rule entries are the control loop itself:

on event#temp_demand>%mem2% do power1 0 endon
on event#temp_demand<%mem3% do power1 %var1% endon

Based on the temperature being above the upper setpoint or below the lower setpoint (which can be controlled by the mem2 and mem3 variables - also exposed via MQTT), it decides if the heater must be turned on or not.

In sum:

mem1 - controls the operational state of the thermostat. Setting it to 'off' turns on the heater. Setting it to 'heat' turns on the heater.

mem2 - controls the lower temperature setpoint in ºC.

mem3 - controls the upper temperature setpoint in ºC.

The other important aspect in this work was defining how to integrate with Again, the Tasmota firmware is comprehensive in this respect, as it provides more than a single option:

At first I attempted the "Belkin WeMo" approach, but upon the lack of success with this approach, soon turned to using MQTT, as in spite of its complexity, it seemed like the more promising one.

The MQTT protocol is a messaging protocol that dates back to well before the home automation hype. It was designed as a more lightweight alternative to traditional messaging protocols, making it useable in low bandwidth scenarios (its first use was to monitor an oil pipeline in the desert).

Enabling the MQTT in Tasmota allows the device to communicate with other agents through a broker.

On the side, I have installed the Mosquitto broker ( Internally (like many modules in it runs in its own docker container:

With this type of architecture, the central system ( doesn't need to be aware of the network details of the individual devices, in order to publish or receive messages from these. This makes it ideal for home automation devices, as these can be plenty, and an easy setup is desired.

I will not go into details in respect to the MQTT setup, as it is well documented in the pages. At the end I defined a user in, and have it configured for read/write access to topics in the MQTT broker:


acl_file /share/mosquitto/accesscontrollist


user homeassistant
topic readwrite #

user sonoff-device
topic readwrite #

this user (sonoff-device) is created in Home Assistant (under Configuration > Users).

In each device (in the Tasmota Web UI), one has to define where the MQTT broker is (host and port), and the credentials of the user that have been created in The topic name should also be defined to distinguish this device from other devices in the network:

Once this is all set, the device should be able to communicate with the broker:

On the broker side it is also possible to confirm that the connection is correctly established:

Finally it is time to proceed with the actual integration of the component (the heater in this case). In this case we want to use the "climate" component for an MQTT source (

In order to add this component, we have to:

  • open the configuration file - /config/configuration.yaml
  • add the entry for the mqtt climate:

  - platform: mqtt
    name: living-room-heater
      - 'off'
      - 'heat'
    mode_command_topic: 'cmnd/living-room-heater/mem1'
    mode_state_topic: 'stat/living-room-heater/RESULT'
    mode_state_template: '{{ value_json["Mem1"] }}'
    temperature_low_command_topic: 'cmnd/living-room-heater/mem2'
#    temperature_low_state_topic: 'stat/living-room-heater/RESULT'
#    temperature_low_state_template: '{{ value_json["Mem2"] }}'
    temperature_high_command_topic: 'cmnd/living-room-heater/mem3'
#    temperature_high_state_topic: 'stat/living-room-heater/RESULT'
#    temperature_high_state_template: '{{ value_json["Mem3"] }}'
    current_temperature_topic: 'tele/living-room-heater/SENSOR'
    current_temperature_template: '{{ value_json.AM2301.Temperature }}'
    action_topic: 'stat/living-room-heater/RESULT'
    action_template: "{{ 'cooling' if value_json['POWER1'] == 'OFF' else 'heating' if value_json['POWER1'] == 'ON' }}"
    qos: 1
    payload_on: 'heat'
    payload_off: 'off'
    payload_available: 'Online'
    payload_not_available: 'Offline'

Here we need to tell three types of information: i) where to obtain the current state of the component; ii) where to send commands; and iii) what fields and values in the data map to values that expects.

The first thing is the modes that our component supports. This is detailed in the documentation, but our heater/thermostat supports the 'off' and 'heat' modes (complete HVAC systems have more possible modes).

The other aspect is where we tell the device to change mode. In this case it is the cmnd/living-room-heater/mem1 mqtt topic (mem1 is the variable we have set in our rule). The line:

mode_command_topic: 'cmnd/living-room-heater/mem1'

defines just that.

The two other aspects, namely:

temperature_low_command_topic: 'cmnd/living-room-heater/mem2'
temperature_high_command_topic: 'cmnd/living-room-heater/mem3'

allow to control the low and high setpoints of the thermostat, as we mentioned in the Tasmota rule part.

Then we also want the component to know the current temperature as reported by the device, and for that we define:

current_temperature_topic: 'tele/living-room-heater/SENSOR'
current_temperature_template: '{{ value_json.AM2301.Temperature }}'

Lastly, we want to know what the heater is actually doing (i.e. if the resistor is turned on or not). For this purpose, we define:

action_topic: 'stat/living-room-heater/RESULT'
action_template: "{{ 'cooling' if value_json['POWER1'] == 'OFF' else 'heating' if value_json['POWER1'] == 'ON' }}"

in order to parse the power status from the messages sent to the topic.

At the end we should have a card in our dashboard that looks like this:

Clicking in the top right corner of the component we obtain more detailed information:

In the future, more improvements are interesting to obtain. For instance, currently the setpoints are optimistically defined in Even though the device reports the feedback of the setpoint having been changed, by publishing to the 'stat/living-room-heater/RESULT' topic:

this information is not interpreted in the climate component, because the later still does not support templates for all the state topics. Ideally the commented code should be supported and allow this feedback to be mapped:

    temperature_low_command_topic: 'cmnd/living-room-heater/mem2'
#    temperature_low_state_topic: 'stat/living-room-heater/RESULT'
#    temperature_low_state_template: '{{ value_json["Mem2"] }}'
    temperature_high_command_topic: 'cmnd/living-room-heater/mem3'
#    temperature_high_state_topic: 'stat/living-room-heater/RESULT'
#    temperature_high_state_template: '{{ value_json["Mem3"] }}'

Until then we only have this optimistic approach. E.g. if setpoints are changed outside, its UI will be out of sync with the device.

Sunday, October 20, 2019

Consumer grade WiFi gear - when fixing the root cause is not at reach

Some time ago, I had to improve the performance and coverage of my home network, so as to be able to use the several devices around the house flawlessly, regardless of the location. Some of these devices have a certain demand for consistent bandwidth, as is the case of the SmartTV for watching IPTV and Netflix, and others such as the smartphones and tablets.

As always I tend to be frugal with spending money in hardware, trying to go with what performs well and is just about enough for the job.

This led me to aim for WiFi gear that would both be somewhat popular and low cost, while at the same time having some hope of being hackable and reflashed to OpenWRT in the future. This was the reasoning when I decided to buy a couple of TP-LINK TL-WR841N routers (with v9 hardware at the time).

At first I set these up and played with the stock firmware, configuring one to play the roles of  NAT, DHCP, DNS, firewall and so on, and the other to act solely as a WDS repeater, allowing WiFi coverage to be extended to the rest of the house.

But later I wanted to play home automation, and more and more felt the need to have these pieces of equipment more manageable. As such I became adventurous, and engaged in the twofold task of managing the frustration of the household users during the periods of service interruption while modifying the routers, and the technical change itself.

The flashing of these devices was a simple step, as the OpenWRT project provides packages which can readily be uploaded and flashed to the devices using the original Web UI. There is no need for setting up any serial connections or anything as such.

Details can be found in the official page:

Given the hardware limitations of these devices (4 MB of Flash and 32 MB of RAM), the sweet spot between features and stability, was using version 15.05.1.

The devices work correctly and the firmware performs quite well in this version, but I found that after a few days of operation and depending on network usage, both the router and the repeater get to a point where the network performance drops dramatically. CPU and memory is not the problem, as during degradation it is possible to patiently open an ssh session and monitor these (e.g. using "top" and "free" commands) and confirm that these are nominal.

Once degradations sets in, it is no longer possible to recover, except by forcing the device restart.

With this in mind and after exhausting the research on corrective solutions, I decided to make a rather generic watchdog script that all it does is measure the ping to a list of destinations, and if none of the destinations is reachable or the minimum ping time is above a given threshold for all destinations, it restarts the device. This allows the impact to be minimized, and reduces the need for manual intervention.

I made this script is available on GitHub, and is generic enough that can be used in other systems where the same kind of problem needs to be dealt with (instead of the reboot command you may configure the appropriate action in your case):

Once the script is copied to the device, you only need to adjust the environment variables to your scenario:

RTT_THRESHOLD - the minimum (ICMP) ping RTT in milliseconds needed for a connection to a given node be considered degraded;

IP_LIST - the list of IP addresses to be tested by the script;

MIN_DEGRADED - the minimum number of nodes from the list that are necessary to have a degraded connection, to assume that the problem is from the device where the script is being executed.

Lastly you need to configure the crontab to run the script at the desired frequency (in this case once every minute):

root@griffinnet-zh-router:~/scripts# crontab -l
* * * * * /root/scripts/ >/dev/null 2>&1

Friday, August 9, 2019

The hurdles of fixing a puncture in a Xiaomi M365 scooter

I can say that I am pretty seasoned at fixing bicycle tires. It dates back to my childhood, where numerous times I had to fix the punctures by patching the inner tubes. I still remember the patching kits featuring an assortment of patches of different sizes and shapes, sanding paper, and the rubber cement.

Never had much trouble in separating the tire from the rim, and putting it back together, after having fixed the puncture. The same applies for fixing the tires of more recent MTBs, where upon following the usual technique no major obstacle arises in accomplishing these tasks.

But now, just after a bit over 100 Km into using my Xiaomi M365 scooter, I found a rattling noise in the front tire while riding it. Went on to take a look, and found a thumb tack, fully buried in the tire. As I started removing it, I could hear the air escaping. Decided to leave it there just so that I could ride the scooter back home.

Obviously the inner tube was punctured. The challenges started with the removal of the two nuts that secured the front wheel. These were incredibly tightened or otherwise held in place. Only after rounding one of the nuts with the most torque I could get my arms to deliver, I learned that these nuts had been secured with the help of red thread lock or similar substance. In order to remove the damaged nut, after many attempts, I haver resorted to a more brute force approach, and started to perform cuts in the nut, in order to remove it in pieces. Just before going further with the cutting, I decided to apply more WD40 and again try to undo it with the round part of the 18 mm wrench (which didn't yet started slipping in spite of the nut being somewhat rounded). Just as I was giving up on the force I was applying, the nut started moving (it seemed like a bit of a miracle), and was able to extract it.

Performed the same procedure with the other nut (not forgetting to bath it with plenty of WD40), and it also came off after some torque (while at the same time being careful not to let to tool slip). Was able to extract the second nut and this one came out intact.

That was challenge #1.

The removal of the tire was relatively easy. With the help of the plastic tools that were part of a bicycle repair kit I had, I was able to separate if from the rim. The inner tube valve would not separate from rim, as there was not enough room for the valve to come off at the required angle. I could not find any other way but to open the motor (rim) cover in order to remove the plastic part that prevented the valve from bending sufficiently to separate from the rim.

Finally with the inner tube removed, and after confirming that it was indeed punctured, and that no damage to the inner wall of the tire existed, I placed the new inner tube (my Xiaomi was supplied with an extra pair of tires and inner tubes) and started trying to put the tire back in place. That was the third hard challenge, and where my bicycle tire repair experience started to prove useless.

After several attempts at closing the tire (the rims seemed too wide for the tire) without success, I (almost desperately) decided to try to use a small vise to deform the tire, with the expectation of making it easier to put it back into the rim.

And to my surprise the technique worked, and without major effort (only with the help of the plastic tools) the tire was successfully put back in place.

I was quite happy with the accomplishment, but as usual, the happiness needed to be offset with some bittersweetness: with so many attempts, the friction of the new inner tube with the rim edges and possibly the tools, caused a puncture to it. I realized after inflating the tire, that it would quickly deflate. As such, I went on and repeated the whole procedure (I still had one spare inner tube left). This time it was quicker because I went straight to the working approach.

By the way, the Xiaomi manual makes the procedure look like a walk in the park:

#4 challenge - obtain the new nut: I knew that online these could be purchased from a variety of different sites, but I wanted to be able to assemble the scooter right away. So I tried to look in local stores for one that would possibly have the nut. After trying a bicycle shop, they gave me the reference of a hardware store. There I was able to find a close enough nut: it had the same thread diameter and pitch, but lacked the flange.

The original Xiaomi nut is flanged and has a M12 1.25 pitch thread. The nut outer diameter is 18 mm.

The nut I obtained from the hardware store has the same thread but the outer diameter is 19 mm.

I tried it anyway, by adding a washer instead, and tightened it with a decent amount of torque.

So far its going pretty solid. Even though the motor exerts some torque, I believe that it should be ok without the thread lock - a inner washer, the shape of the motor shaft and receptacle in the frame prevents its rotation/slipping.

For those curious about the hub motor inner workings:

It seems to have a reasonably robust construction, with the wiring properly secured and protected.

Saturday, July 13, 2019

EDF Propelled Hovercraft project - first outdoor test

Following the post regarding the construction of this project, here is finally the first real test:

Performance and handling are very good, as expected.

Monday, July 8, 2019

The most inneficient (and probably the coolest) EV in the world - the electric hovercraft!

This project may well model what an electric hovercraft could feel like to drive. At least from a noise perspective, trust me, it is a pretty solid preview in spite of its small scale!

This whole project started out with an inspection of my inventory of spare R/C parts, and with a little brainstorming with my daughter, figuring out something fun to build from scratch without spending too much money, this came to mind. Sketch after sketch, the idea went from a concept, to a plan, and lastly to the actual construction:

Considering the importance, and thank god, apparent focus of the legislators and the industry in replacing vehicles that burn fossil fuels with greener alternatives, it is interesting and of great importance, to also promote and bring to the recreational arena, the electric vehicle in its diverse shapes, purposes and forms.

One of the approaches (which we already see to some extent taking place in several communities) is to pick certain collectible cars, and especially when the restoration of the engine is a greater challenge, go for the replacement of the original propulsion, with an electric drivetrain. Depending on the specific model of the vehicle, the electrification has a variable level of difficulty and cost, but also tends to bring mechanical simplicity and interesting performance.

The automobile is probably the most popular form of motor vehicle.

In its electric form, it is somewhat thanks to companies like Nissan and Tesla with their consumer EVs becoming widely available, that performance and range was proven possible (to consumers) in vehicles powered only by electricity:

In recent years, electric drivetrains also gave shape to entirely new forms of vehicles - that is the case for Segway scooters, and other devices with a similar concept, such as the hoverboard.These vehicles would hardly be possible without the advancements in recent decades, regarding digital control and the sophistication of sensors such as the MEMS gyros and accelerometers.

But it is hardly a conventional though, to look at exotic vehicles such as the hovercraft, and think of making an electric variant of it.

The hovercraft is conceptually simple: it consists of a frame which holds a powered propeller, mounted in the horizontal plane, and one or more propellers mounted vertically in the rear of the vehicle. The later is (are) responsible for providing the forward thrust to the vehicle, while the horizonal propeller creates the dynamic pressure under the vehicle, providing an air cushion that eliminates the drag from the contact with the ground.

In my design, I looked forward to making it simple and minimize the need to buy new parts. I was able to repurpose one brushless motor (which I initially used for powering an airplane), for serving as the air cushion propulsion source, and some aluminium tubing which I used as support for the motor:

The 3 ESC's (Electric Speed Controller), a power distribution board, two 9 gram servos, and the two 2.2 Ah 11.1 Volt  3S LiPo batteries I was also able to take from my R/C stock and use it in the vehicle.

The radio receiver and transmitter I  reused from the available R/C gear I had:

The rest however, I ended up having to buy: the polystyrene used for the frame, the two ducted fans, and 4500 KV brushless motors that are attached to these.

Instead of the usual skirt, I went for a design simplification, by using a lightly inflated 16" bicyle inner tube instead of it:

For cutting the polystyrene to the shape of the frame, I developed a technique which I plan to explain in a later post.

For control, 5 R/C channels are used in total:

Channel 1: left EDF thrust vectoring servo;
Channel 2: right EDF thrust vectoring servo;
Channel 3: left EDF motor;
Channel 4: right EDF motor;
Channel 5: air cushion motor.

With this setup, and given the fact that I am using a programmable transmitter (powered by OpenTX), it is possible to fine tune mixes and mappings between stick input and channel output in a way that makes it simple for the operator to control the vehicle, and optimal use of the motors and control surfaces is achieved.

For instance, for controlling the steering, I went for a combination of thrust vectoring and differencial throttle control - when the vehicle is being steered left or right, less power is applied to the left or right motor respectively, while the entire  EDF assembly is turned right or left at an angle proportional to the user input. Experimentally I verified that using thrust vectoring alone, it would cause translation of vehicle instead of the desired yaw angle together with the change in direction.

Two curves were configured, in order to define the thrust vectoring + differential throttle mix explained above:

Another curve was defined, in order to mix the throttle stick input with the air cushion motor.

This would remove the need for having to use a separate control input for turning this motor on and off, therefore allowing for some energy savings. I preserved however, the use of a separate potentiometer in the TX, for adjusting the maximum speed of this motor.

As of this writing one a few indoor tests were conducted (potentially at the expense of the good relationship with the neighbors living in the adjacent apartments). Those were enough to prove that if  single EDF is painfully loud, 2 EDFs and a propeller is worse than a unmuffled motorcycle running at wide open throttle.

Stay tuned for the video featuring an outdoor test of the machine (with people with earplugs around it).

Sunday, June 23, 2019

DSLR Intervalometer - Source code made available in GitHub

For those who remember my work back in the days with implementing an intervalometer for Nikon cameras (yes, in spite of it being rather simple to implement in the camera firmware itself, these larger brands prefer to classify such a feature as premium and make it available only in more expensive DSLRs), I have detailed in the following post, the solution that I have put together:

Initially I built the Intervalometer to control (via a wired interface) a Fujifilm S9600 camera, but later I have converted the design to include an IR transmitter, and as such be usable with practically any Nikon DSLR with an IR-remote port (normally used with the ML-L3 IR remotes that are sold separately). This device mimics the ML-L3, and furthermore it has the intervalometer capability.

I have now made the project schematics and firmware source code available in GitHub, for those who wish to build the solution or contribute/fork/take as inspiration for a new project. You can find it in my GitHub section, under:
